Beschreibung
- Hign-betroffene Chemikalie: Keine
- AI Funktionen: Bewegung Dedection
- Shell-Material: Metall
- Farbe Nachtsicht: no
- Betriebstemperatur: -10°C to 50°C
- IP Bewertung: Ip67
- Power Modus: Netz Strom
- Scene: Indoor und Outdoor
- Pixel: 5mp
- Stromversorgung: Mit POE
- Installation: Decke,Normal,Wand Montiert
- Farbe: WHITE
- ist individuell: Ja
- Audio-Ausgang: Zwei Weg Audio
- Minimale Beleuchtung( Lux): 0.006 lux@F2.0 (Color, 30 IRE)
- Video-Kompressions-Format: mjpeg,H.264,H. 265
- Ir-Abstand (M): 10m
- Maße( L x B x T)( mm): 44.6 mm * 126.2 mm
- alarm Aktion: ftp foto,lokalen alarm,E-foto
- unterstützten mobilen Systeme: Android,IOS
- Sensormarke: Sony
- Spezielle Eigenschaften: Wasserdicht/Wetter
- Sensor: CMOS
- Modellnummer: IPC-EW5541-AS
- unterstützten Betriebssysteme: Windows 7,windows 10,Mac OS
- Objektiv (mm): 1,44mm
- Anschließung: IP/Netzwerk verdrahtet
- Hohe Definition: 5,0 Megapixel
- Art: Fisheye Kamera
- Markenname: Ziksecu
- Ursprung: CN (Herkunft)
Dahua Original IPC-EW5541-AS 5MP POE WizMind Fisheye IP CAMERA Built-in MIC SD Card Slot & Alarm I/O H.265 Intelligent Detection
5MP WizMind IR Fisheye Network CAMERA
> 5MP, 1/2.7" CMOS image sensor, low illuminance, high image definition
> Outputs max. 5MP (2592 × 1944) @25/30 fps
> H.265 codec, high compression rate, ultra-low bit rate
> Built-in efficient IR illuminator, and the max. illumination distance: 10 m
> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments
> 120dB WDR, 3D DNR, HLC, BLC, digital watermarking, applicable to various monitoring scenes
> Intelligent detection: Intrusion, tripwire, people counting in area
> Abnormality detection: Motion detection, video tampering, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection
> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card, built-in Mic
> 12V DC/PoE power supply, easy for installation
> Heat map for people counting. You can adjust the number of people, time threshold to generate a heat map, which can be exported.
Model: IPC-EW5541-AS
Camera:
Image Sensor：1/2.7" 5Megapixel progressive CMOS
Max. Resolution:2592 (H) × 1944 (V)
ROM: 128 MB
RAM: 512 MB
Scanning System: Progressive
Electronic Shutter Speed: Auto/Manual 1/3 s–1/100,000 s
Min. Illumination: 0.006 lux@F2.0 (Color, 30 IRE)
0.0006 lux@F2.0 (B/W, 30 IRE)
0 lux (Illuminator on)
IR Distance: 10 m (32.8 ft)
IR On/Off Control: Auto/Manual
IR LEDs Number: 3
Lens:
Lens Type: Fixed-focal
Mount Type: M12
Focal Length: 1.4 mm
Max. Aperture: F2.0
Field of View:
Horizontal: 180°
Vertical: 180°
Diagonal: 180°
Iris Type: Fixed
Close Focus Distance:0.2 m (0.7 ft)
Smart event
Heat Map：yes
Intelligent
IVS(Perimeter Protection): Tripwire; intrusion
People Counting：Support people counting in area, and displaying and outputting yearly/monthly/daily reports (matching devices are needed); support people counting in 4 areas
Intelligent Search：Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos.
Video
Video Compression: H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream)
Smart Codec: Yes
Video Frame Rate:
Main stream: (2592 × 1944 @1–25/30 fps)
Sub stream: 704 × 576@ (1–25 fps)/704 × 480@ (1–30 fps)
Stream Capability：3 streams
Resolution: 5M (2592 × 1944); 3M (2048 × 1536); UXGA (1600 × 1200); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
Bit Rate Control: CBR/VBR
Video Bit Rate:
H.264: 3 Kbps–8192 Kbps
H.265: 3 Kbps–8192 Kbps
Day/Night: Auto(ICR)/Color/B/W
BLC: Yes
HLC: Yes
WDR: 120 dB
White Balance: Auto/natural/street lamp/outdoor/manual/regional custom
Gain Control: Auto/Manual
Noise Reduction: 3D DNR
Motion Detection: OFF/ON (4 areas, rectangular)
Region of Interest(RoI): Yes (4 areas)
Smart IR: Yes
Privacy Masking: 4 areas
Audio
Built-in MIC: Yes
Audio Compression: G.711a; G.711Mu; G.726；PCM
Network:
Network: RJ-45 (10/100 Base-T)
SDK and API：Yes
Protocol: IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; SNMP
Interoperability: ONVIF (Profile S/Profile G/Profile T); CGI; Milestone; Genetec; P2P
User/Host: 20 (Total bandwidth: 64 M)
Edge Storage: FTP; SFTP; Micro SD card (support max. 256 GB)：NAS
Browser: IE；Chrome ；Firefox
Management Software: Smart PSS：DSS; DMSS
Mobile Phone: IOS; Android
Certification
CE-LVD: EN62368-1;
CE-EMC: Electromagnetic Compatibility Directive2014/30/EU;
FCC: 47 CFR FCC Part 15, Subpart B;
UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07
Power
Power Supply: 12V DC/PoE (802.3af)
Power Consumption: Basic power consumption: 3.6W (12V DC); 4.4W (PoE)
Max. power consumption (H.265 + IR on+ intelligent function + WDR): 7.3W (12V DC); 8.8W (PoE)
Environment
Operating Temperature: –10°C to +50°C (14°F to +122°F)/Less than 95% RH
Storage Temperature: –40 °C to +60 °C (–40 °F to +140 °F)
Structure
Casing: Metal + Plastic
Dimensions: 44.6 mm × Φ126.2 mm (1.8" × Φ5.0")
Net Weight: 299 g (0.7 lb)
Gross Weight: 441 g (1.0 lb)
